- Rotary Vane Pump/Motor Assembly Series 5- 105A215F32XX712
Rotary Vane Pump/Motor Assembly Series 5- 105A215F32XX712
Product Type: Other Industries
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
215GPH
650LPH
Series 5
Stainless Steel
Clamp-On
Non-food grade (1.5% Max Lead) - No Agency Approval
NPT 1/2"
Non Balances Ceramic/Carbon
-4°F
194°F
100cP
2400RPM
AC
PROCON
450VAC
Special Clearance for High Temperature Applications
External Fan Cooled
Double Flat
3.3ft
2pH
50Hz
84138100
Carbon
250psi
60dB(a)
100psi
1000RPM
14?F
4.2A
IMB3
F
Clamp-On
4
PSC
0.75
Single Phase
0.75
560W
Pump/Motor Assembly
105A215F32XX712
STD Rotary Vane Pump
V5A
7585bb1a-8d33-4080-9f12-c7e29d8e27eaF1002.pdf
24.33lb (11.04Kg)
IP55
Clockwise
1360RPM
Piece
Znode Multifront
230V
6.6ft
- Details
- Features
- Applications
- Documents
Flow Rate GPH
215GPH
Flow Rate LPH
650LPH
Series
Series 5
Material
Stainless Steel
Mount
Clamp-On
Agency Approvals
Non-food grade (1.5% Max Lead) - No Agency Approval
Standard Ports
NPT 1/2"
Seal Type
Non Balances Ceramic/Carbon
Min Fluid Temperature
-4°F
Max Fluid Temperature
194°F
Max Fluid Viscocity
100cP
Max Speed
2400RPM
Motor AC/DC
AC
Brand
PROCON
Motor Capacitor Voltage
450VAC
Internal Component Clearance High Temp Applications
Special Clearance for High Temperature Applications
Motor Cooling
External Fan Cooled
Drive Configuration
Double Flat
Dry Suction Lift
3.3ft
Fluid Acidity
2pH
Motor Hertz
50Hz
HSS Commodity Code
84138100
Internal Component Material
Carbon
Max Discharge Pressure
250psi
Max Sound Level
60dB(a)
Max Static Pressure PSI
100psi
Min Speed
1000RPM
Motor Capacitor
14?F
Motor Current 1
4.2A
Motor Design
IMB3
Motor Insulation
F
Motor Mount Type
Clamp-On
Motor Poles
4
Motor Type
PSC
Motor Voltage 2
0.75
Motor Phase
Single Phase
Motor Power 2
0.75
Motor Power 1
560W
Product Classification
Pump/Motor Assembly
Product Code
105A215F32XX712
Product Family
STD Rotary Vane Pump
Product Family Sub Group
V5A
Product Performance
7585bb1a-8d33-4080-9f12-c7e29d8e27eaF1002.pdf
Product Weight
24.33lb (11.04Kg)
Motor Protection
IP55
Rotation
Clockwise
Motor Speed 1
1360RPM
UOM
Piece
Vendor
Znode Multifront
Motor Voltage 1
230V
Wet Suction Lift
6.6ft
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
